Wharfedale Diamond 12 Owner's Thread

No reasonable loudspeaker has a 20 dB spike so low,
Nor does any microphone. But room modes caused by reflections can, and often do, result in such responses. Measurements taken from a couple of threads here:

Screenshot 2024-12-22 at 07.58.39.pngScreenshot 2024-12-22 at 08.01.38.png

Last edited:
Nor does any microphone. But room modes caused by reflections can, and often do, result in such responses. Measurements taken from a couple of threads here:

View attachment 415648View attachment 415649
I agree that typical measurements mics don't have such large and relatively low frequency peaks but even on such measurements as it can be seen usually not a single discrete 20 dB(!) peak appears in that region, I have done in the last years more than 1000 loudspeaker measurements and never seen something similar.
I have the Diamond 12.2 speakers. When i run room correction on my Wiim amp it shows a big spike up to 20db at 8khz. Different phones give the same results. Weird thing is i don't hear it, sounds great to me. If I allow the room correction to 'correct' that high it sounds terrible, extremely muffled.
Could you post some screenshots of those?

  • Like
Reactions: MAB
I have done in the last years more than 1000 loudspeaker measurements and never seen something similar.
I agree that we'd need to get into the specifics of test method, measurement location, measurement kit, room set up and equipment etc to start to get a handle on what is going on.

I agree that we'd need to get into the specifics of test method, measurement location, measurement kit, room set up and equipment etc to start to get a handle on what is going on.
Using my Motorola Edge phone mic, latest Wiim software update, measured from sofa about 10 foot in front of speakers. Speakers are at either end of a tv cabinet. Right speaker has lots of clear air around, left speaker has a wall to one side about 2 feet away.

The same spike shows up using a different phone mic (Pixel 8).


Attachments

  • Screenshot_20241230-110205.png
    186 KB · Views: 33
Using my Motorola Edge phone mic, latest Wiim software update, measured from sofa about 10 foot in front of speakers. Speakers are at either end of a tv cabinet. Right speaker has lots of clear air around, left speaker has a wall to one side about 2 feet away.

The same spike shows up using a different phone mic (Pixel 8).
That spike at nearly 8kHz is very unlikely to be a room mode. Wavelength is only about 4cm. At least if it was, it would fade in and out for every 1 or 2cm moment of the microphone.

The only other thing I can think of is resonance. Possibly something in the speaker or room is ringing at 8kHz.

Or android - or the app has an error in making the measurement. Do you have another system or smart speaker you can measure.

What happens if you do a near field measurement - within a cm or two of the tweeter.

How do 12.1s or 12.2s sound when placed on their side rather than bottom, and close (say 2in.) to a wall? Boomy bass and muddy mids? I wonder if my ageing ears will notice much difference!
I'd be glad to hear of anyone's experiences and experiments

How do 12.1s or 12.2s sound when placed on their side rather than bottom, and close (say 2in.) to a wall? Boomy bass and muddy mids? I wonder if my ageing ears will notice much difference!
I'd be glad to hear of anyone's experiences and experiments
close to wall placement - almost guaranteed boost in the 150-300Hz range for any speakers. but I've attenuated that range with room correction

That spike at nearly 8kHz is very unlikely to be a room mode. Wavelength is only about 4cm. At least if it was, it would fade in and out for every 1 or 2cm moment of the microphone.

The only other thing I can think of is resonance. Possibly something in the speaker or room is ringing at 8kHz.

Or android - or the app has an error in making the measurement. Do you have another system or smart speaker you can measure.

What happens if you do a near field measurement - within a cm or two of the tweeter.

Just got around to doing this. Near field also shows a big spike in the same region, up to almost 20db.

Using a different speaker from the original listening position also shows the same spike as the original screenshot.

Trying a different phone shows the same shape spike just shifted to around 10khz.

Is the Wiim room correction software just useless? Has anyone got any decent results with it?

Using a different speaker from the original listening position also shows the same spike as the original screenshot.
Could still be something in the room resonating. Can you test in a different room. (EG long speaker wire to allow speaker to be placed elsewhere)

Oh - and can you hear this. A 20dB spike at 8kHz should be clearly audible.

Could still be something in the room resonating. Can you test in a different room. (EG long speaker wire to allow speaker to be placed elsewhere)

Oh - and can you hear this. A 20dB spike at 8kHz should be clearly audible.

Yep, very similar results in a different room. I think it must be a software or mic issue which is occuring on both phones I've tried. I can't image it's real, like you say I would notice it.
