Boy, these are rough. Before even looking at the data and just listening to the pink noise vs filtered pink noise, I could tell something was wildly wrong.
- Extremely bad pair matching
- Frequency response and directivity (especially vertically) is just plain bad - looks like no XO on the woofer at all, from what I can tell.
- Badly designed cabinet - high Q upper bass resonance around 80hz, then rapid fall-off with a very vague EBS-like alignment, almost looks like a poorly implemented transmission line. Maybe too small of a box for the driver's T/S parameters? UPDATE: No "Maybe" about it, the box is way too small for this.
- Distortion is nothing to write home about either.
- Very low sensitivity, a bit above 81dB/2.83V.
