picture is a dual TPA3255 amplifier board I am experimenting with. Chips on the bottom are input opamps. Chips above them with thermal paste on them are TPA3255. Square devices with number 100 are called inductors. Next to them are capacitors (red). The capacitors and inductors form an output filter to block most of the high frequency switching noise from the output transistors. Switching frequency is typically somewhere between 425-650 Khz. All class D amps have these filters. Quality of the inductors and capacitors has impact on distortion and SNR.
